Success Stories

Success Stories

Major Telecommunications Company

A major telecommunications firm with production sites located in CSC shared data centers in Connecticut and Delaware was purchased by a major dot-com and used Cirrus Migrate to consolidate its data from the two data centers to one with no downtime required until cutover.

A major telecommunications firm with production sites located in CSC shared data centers in Connecticut and Delaware was purchased by a major dot-com and used Cirrus Migrate to consolidate its data from the two data centers to one with no downtime required until cutover.

Customer Type

Customer Type

Major Telecommunications Company

Major Telecommunications Company

Customer Sector

Customer Sector

Telecommunications

Telecommunications

Source Storage

Source Storage

EMC vPlex

EMC vPlex

Target Storage

Target Storage

Various

Various

Number of Hosts & Clusters

Number of Hosts & Clusters

11

11

Host Types

Host Types

Windows, Solaris, ESX

Windows, Solaris, ESX

Host Applications

Host Applications

Database, Application, Web, File Servers

Database, Application, Web, File Servers

Replication Type

Replication Type

Remote

Remote

Number of CMO and model

Number of CMO and model

8x CMO4000

8x CMO4000

Insertion Method

Insertion Method

Host Side

Host Side

Challenges

• Migrate two shared data centers — one in Delaware and one in Connecticut — to a new Google Colocation data center in Virginia

• No downtime allowed until cut-over

• Migration must take place using MPLS WAN connections

• Shared data center does not allow performance impact to other tenants who share the storage

Solution

• CMO appliances can be deployed for migration using host-side insertion, which adheres to multi-tenant security requirements

• CMO facilitates mapping of entire SAN even when using host-side insertion, allowing client LUNs to be identified for migration

• Simultaneous migration of both sites can be accomplished using remote migration, with data consolidated on destination storage

• CMO allows cut-over to new storage to be conducted in minutes once migration has completed

Results

• No downtime was necessary for deployment, and no changes were made to shared storage infrastructure

• Remote migration allowed consolidation of two data centers in two states to be consolidated at one site in a third state

• The simplicity of CMO allowed entire migration operation to be managed remotely

• Host-side insertion provided storage migration from a complex IaaS multi-tenant environment

The Story

When a major telecommunications firm with production sites located in CSC shared data centers in Connecticut and Delaware was purchased by a major dot-com, the dot-com decided to consolidate the storage to a Google Colocation facility in Virginia.

The CSC data centers required any migration appliance to pass a colocation security scan and to operate in lock-down mode. Additionally, since the data center was a multi-tenant environment, there were restrictions on attaching anything to shared storage arrays. Adding to the complexity of the migration, no downtime would be tolerated until cut-over.

Cirrus Data’s Cirrus Migrate On-Premises (CMO), with its patented TDI technology and ease of use, made it the perfect choice for this migration. CMO’s flexibility allowed the appliance to be inserted on the hostside, where no changes to the storage environment and no downtime would be necessary. Since the data centers were hosted in three different states, CMO demonstrated the ability to migrate a large amount of data using only TCP/IP connections with compression and encryption. Utilizing CMO’s auto-allocation feature, the entire SAN was mapped (even with host-side insertion), allowing client LUNs to be identified for migration and new LUNs to be automatically created on the destination storage and matched with existing host LUNs, alleviating the need for hours of manual and error-prone processes.

The entire migration operation was managed remotely by a team of IT professionals and once again proved that CMO is the least intrusive way to migrate and consolidate storage among different storage subsystems in multiple locations. The purchasing dot-com was able to successfully access all application servers and data from its data center in a timely manner and was extremely pleased with CMO’s friendly usability and I/O efficiency.
